Silicone Semi-finished Tube
Category：Silicone Semi-finished Tube
Temperature: -40℃ ~ +200℃
Material: silicone
Color: Red
Product description: Silicone semi-finished tube is continuously extruded with primary vulcanization only, supplied in rolls or long lengths for customer secondary processing including cutting, punching, bonding and post-curing. Platinum cured grade meets FDA, LFGB, USP Class VI, suitable for food, medical, pharmaceutical and electronic industries. Features outstanding high & low temperature resistance, good elasticity, ozone, UV and weather aging resistance.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Product Overview
Silicone semi-finished tube is continuously extruded silicone tubing with primary vulcanization only. It is supplied in rolls or long straight lengths without secondary processing. Customers can further cut, punch, bond, post-cure or assemble the tube into finished parts such as sleeves and fluid conduits. It differs from finished silicone tubes which are pre-cut, cleaned and packaged for direct end use.
Manufacturing Process
- Mix raw silicone compound with curing agent, color masterbatch and functional fillers
- Extrude into hollow tube profile
- Primary continuous vulcanization by hot air or steam
- Online dimension inspection
- Winding into rolls or long stock bars for semi-finished delivery
Subsequent operations: cutting, slitting, punching, bonding, post-curing, surface treatment and assembly to be completed by customers.
Technical Specifications
- Hardness: 30 ~ 80 Shore A, common grades 50 / 60 / 70 Shore A
- Density: 1.12 ~ 1.25 g/cm³
- Temperature resistance:
- Standard grade: -40℃ ~ +200℃
- Special low-temperature grade: -60℃ ~ +250℃
- Tensile strength: 7 ~ 10 MPa
- Elongation at break: 350 ~ 720 %
- Tear strength: 25 ~ 55 kN/m
- Good low compression set for sealing applications
- Dimensions: ID, OD, wall thickness
- Size range: ID 0.3mm up to OD 80mm; wall thickness 0.5 ~ 10mm
- Tolerance: standard ±0.1mm; precision grade ±0.05mm
- Color: translucent / clear, white, black, red, custom Pantone colors available
- Reinforcement: plain unreinforced; fabric braided reinforced option for higher pressure resistance
Product Properties
- Excellent high and low temperature resistance
- Great flexibility, high elasticity and low permanent deformation
- Outstanding resistance to ozone, UV and weather aging
- Reliable electrical insulation performance
- Chemically inert to weak acid, weak alkali, alcohol and water
- Not recommended for long-term contact with mineral oil, hydrocarbon solvents, strong acid or strong alkali
