Copper Powder Filled PTFE KZT Spring Energized Seal
High Temperature Anti-Wear Copper Filled PTFE KZT Sealing Solution
This KZT type copper powder filled PTFE seal is specially developed for high-temperature working conditions. Adding copper powder into PTFE greatly improves thermal conductivity, high-temperature dimensional stability and anti-wear performance, while retaining the original self-lubrication and chemical stability of PTFE. Cooperated with spring energized structure, it can automatically compensate clearance deviation and thermal expansion deformation under long-term high temperature operation. It is a preferred high-temperature resistant sealing choice for metallurgy, thermal power and high-temperature hydraulic equipment.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
1.Product Advantages
Copper powder filling greatly enhances thermal conductivity, helping rapid heat dissipation and avoiding high-temperature aging failure. Excellent high-temperature dimensional stability, not easy to soften or deform under long-term heat environment. Good wear resistance and low friction coefficient reduce shaft wear and adapt to frequent reciprocating and rotating motion. Fine chemical inertness resists common industrial oil and medium erosion without swelling or cracking. Spring compensation structure keeps stable sealing performance even under temperature difference and pressure change.
2.Working Principle
After installation, the internal stainless steel spring provides lasting radial preload, making the copper powder filled PTFE sealing lip closely fit the mating surface. Under system working pressure, the contact tightness is further increased to form stable static and dynamic sealing. Copper powder ingredient optimizes thermal conductivity and high-temperature resistance, quickly conducting heat and preventing seal softening and creep at high temperature. The spring structure automatically makes up for wear, assembly gap and thermal deformation, maintaining long-term stable and leak-free sealing under alternating high temperature and pressure.
3.Product Details
Sealing main body is made of copper powder blended modified PTFE, equipped with high temperature resistant and anti-fatigue stainless steel spring. All specifications are produced according to KZT standard sealing groove size. Each batch is strictly tested for high temperature stability, thermal conductivity, wear resistance and medium adaptability. All products comply with industrial safety and environmental regulations, adopting independent dust-proof and moisture-proof sealed packaging, matched with export cartons for storage and bulk delivery.
4.Application Range
Fit for metallurgical machinery, thermal power equipment, high-temperature hydraulic system, industrial furnace auxiliary equipment, high-temperature pipeline valves and heat treatment machinery. Perfect for continuous high temperature, heat dissipation required, frequent movement and medium corrosion sealing scenarios.
5.Core Performance Parameters
Operating Temperature Range: -30℃ to 280℃
Friction Coefficient: ≤0.10
Copper Powder Filling Ratio: Customizable per actual working condition
Static Pressure Resistance: Up to 45MPa
Dynamic Pressure Resistance: Up to 30MPa
High Temperature Creep Rate: ≤3% (250℃, 24h)
Friction Coefficient: ≤0.10
Copper Powder Filling Ratio: Customizable per actual working condition
Static Pressure Resistance: Up to 45MPa
Dynamic Pressure Resistance: Up to 30MPa
High Temperature Creep Rate: ≤3% (250℃, 24h)
6.Forever Seals’ Selling Points
Focusing on high-temperature special sealing field for 17 years, Forever Seals masters independent formula adjustment technology for copper powder filled PTFE materials. We adopt precise raw material proportioning and constant temperature process treatment to ensure stable thermal conductivity and high-temperature deformation resistance of each batch. We support KZT standard conventional models in stock, as well as non-standard size customization and copper powder ratio personalized adjustment. Our technical team provides targeted high-temperature working condition matching, sealing scheme optimization and complete after-sales support, professionally solving various high-temperature sealing bottlenecks for industrial customers.
