Industrial Bakelite Handle Ball, Oil-Proof Non-Conductive Knob with Metal Insert
- Category：Industrial Handle Parts
- Temperature: 150–200℃
- Material: Phenolic plastic (PF), made of phenolic resin mixed with wood powder/asbestos filler, cured at high temperature and pressure (thermosetting plastic, non-re-meltable)
- Color: Yellow (black and red are the most commonly used colors)
- Hardness: High hardness, smooth and wear-resistant surface, comfortable to hold, not easy to wear during long-term use
- Product description: This bakelite handle ball (also known as phenolic handle ball) is a high-performance thermosetting plastic operating part, designed for industrial, high-temperature and insulation scenarios.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
1. Material and Characteristics
-
Material: Phenolic resin + wood powder/asbestos filler, cured at high temperature and pressure, cannot be melted again.
-
Core Performance
-
Heat Resistance: No deformation at 150–200℃ for a long time, far superior to ordinary plastics (60–120℃).
-
Insulation: Non-conductive, suitable for the operation of electrical tools and live equipment.
-
Environmental Resistance: Oil-resistant, acid-alkali-resistant and moisture-proof, durable in harsh environments.
-
High Hardness: Smooth and wear-resistant surface, comfortable to hold.
-
-
Disadvantages: High brittleness, fear of heavy impact, poor elasticity.
2. Specifications and Models (JB/T 7271.1)
-
Types
-
Type A: No metal insert, bakelite thread, low cost.
-
Type B: Embedded with brass/iron thread, high strength, detachable and reusable.
-
-
Common Sizes (Thread × Ball Diameter): M6×20, M8×25, M10×32, M12×40, M16×50.
-
Colors: Standard black, bright red, industrial blue, orange, milk white; black/red are the most commonly used.
3. Main Applications
-
Industrial Machinery: Adjustment knobs and handles for machine tools, combined machine tools and woodworking machinery.
-
High-Temperature Equipment: Handles for electric soldering irons, electric welding machines, ovens, boilers and heat treatment equipment.
-
Valves and Pipes: Operation heads for plumbing, gas and industrial valves.
-
Electrical Tools: Non-slip grips for screwdrivers, wrenches and insulated pliers.
4. Comparison with Ordinary Plastic Handle Balls
|
Comparison Items
|
Bakelite Handle Ball
|
Ordinary Plastic (ABS/PP) Handle Ball
|
|---|---|---|
|
Heat Resistance
|
150–200℃
|
≤120℃, easy to deform
|
|
Insulation
|
Excellent
|
General
|
|
Durability
|
Oil-resistant, wear-resistant, long service life
|
Easy to age and wear
|
|
Cost
|
Medium-high
|
Low
|
|
Scenarios
|
Industrial/high-temperature/insulation
|
Normal temperature/household/low load
|
5. Selection Suggestions
-
High-temperature/insulation scenarios: Prioritize Type B bakelite handle ball (metal insert is more durable).
-
Normal temperature and low load: Type A or ordinary plastic models can be selected to control costs.
-
Thread specification: Choose M6–M16 according to the equipment shaft diameter, and the ball diameter matches the holding space.
-
Color: Black is universal, and red is used for emergency/safety operations.
