VB Type External Skeleton Oil Seal for Rotating Shafts
Single Lip, Spring-Free Design for Light Dust Environments
Tailored for rotating shaft applications, this seal integrates a robust outer metal case with a flexible inner rubber body, paired with a single-lip, spring-free design that minimizes friction during operation—critical for reducing wear on low-speed components. It excels at grease sealing in light-dust environments, making it a go-to choice for low-speed bearings and equipment where dust intrusion is mild. Engineered for non-pressurized scenarios (max. pressure ~0.03MPa), it avoids leakage risks in low-stress setups.
Crafted from high-performance materials, it offers two reliable options: NBR for strong oil resistance (ideal for standard industrial oils) and FKM for superior heat and chemical resistance (suited for high-temperature or corrosive environments). Precision-manufactured to fit diverse shaft sizes, it ensures secure installation and long-lasting lubrication retention. Balancing durability, ease of use, and targeted performance, it streamlines your selection process for sealing needs in low-dust, low-pressure equipment.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
1. Product Advantages
Low-Friction Operation: The single-lip, spring-free design minimizes contact friction with rotating shafts, reducing component wear and extending the service life of both the seal and connected equipment (e.g., low-speed bearings).
Dual Material Options: Available in NBR (excellent oil resistance for standard industrial oils) and FKM (superior heat resistance up to 200°C/392°F and chemical resistance for harsh environments), meeting diverse application needs.
Reliable Sealing Performance: The outer metal case ensures structural stability during installation, while the inner rubber body tightly adheres to shafts, preventing grease leakage and blocking mild dust intrusion (suitable for light-dust environments).
Cost-Effective Durability: Precision manufacturing by Forever Seals guarantees consistent quality, reducing frequent replacement costs and maintenance downtime for your equipment.
2. Working Principle
The VB type seal operates on a "static + dynamic sealing" mechanism:
Static Seal: The outer metal case (fixed to the equipment housing) forms a tight fit with the housing, preventing grease leakage from the static gap.
Dynamic Seal: The inner rubber lip (in contact with the rotating shaft) creates a micro-sealing interface. As the shaft rotates, the lip retains lubricating grease inside while blocking external light dust—its spring-free design reduces friction without compromising sealing efficiency, ideal for low-speed rotation.
3. Product Details
Structure: Outer metal skeleton (for rigidity) + inner rubber sealing element (for flexibility); single-lip design, no spring.
Pressure Resistance: Max. operating pressure ~0.03MPa (non-pressurized scenarios only).
Dimensions: Multiple precision-machined sizes available (e.g., 58805mm, 20023016mm) to fit various shaft diameters, ensuring a perfect match for your equipment.
Quality Assurance: Each seal undergoes strict leakage and wear testing before leaving the factory, complying with international industrial standards.
4. Application Range
Industrial Equipment: Low-speed bearings in conveyors, packaging machines, and small electric motors.
Mechanical Systems: Grease-sealed components in agricultural machinery (e.g., small tractors) and construction tools (e.g., handheld drills) with mild dust exposure.
Automotive Auxiliaries: Non-pressurized rotating parts in car air conditioning compressors and power steering pumps (using NBR/FKM variants as needed).
5. FAQ
Q1: Can the VB seal be used in high-pressure environments?
A1: No. It is designed for non-pressurized setups (max. ~0.03MPa); high pressure will cause leakage. For high-pressure needs, contact Forever Seals for custom solutions.
Q2: How to choose between NBR and FKM materials?
A2: Choose NBR for standard oil-based lubricants and temperatures below 120°C/248°F; select FKM for high-temperature (up to 200°C/392°F) or chemical-exposed environments (e.g., contact with solvents).
Q3: What is the service life of this seal?
A3: Under normal use (light dust, low speed, correct installation), it typically lasts 1–2 years. Service life may vary based on operating conditions—Forever Seals provides after-sales support for installation guidance.
6. Forever Seals’ Selling Points
20+ Years of Expertise: Specialized in sealing solutions, with a track record of delivering reliable products for global industrial clients.
Customization Capability: Offer tailor-made size and material modifications to fit unique equipment requirements.
Global After-Sales Service: Provide technical consultation, installation guidance, and replacement support via 24/7 online channels, ensuring a seamless user experience.
Eco-Friendly Production: Use lead-free, RoHS-compliant materials, aligning with environmental standards and sustainable development goals.
